Feedthrough type (HDMI on front and back)
Gold-plated contacts
Zinc diecast housing
This 3.5 mm, right-angled stereo jack plug has an all-metal, slim design with gold-plated contacts and chuck type strain relief. It is suitable for cables with a diameter from 2 to 4.5 mm, tailored for professional headphones.
Mechanical Specifications
Length (mm) 38.8 mm
Height (mm) 31 mm
Width (mm) 26 mm
Diameter 23.6 mm
Weight 0.1 kg
IP Rating IP20 (indoor use only)
Housing Zinc
Colour Black
Product Properties
Locking Device Latch
Thermal Specifications
Maximum Ambient Temperature 85 °C
Minimum Ambient Temperature -25 °C
Electrical Specifications and Connections
Brand Connector 1 Seetronic
Data Connector in HDMI
Data Connector out HDMI
Pins 19
