180 W dimmable RGB(W) LED driver
Four channels
Smooth, flickerfree dimming
Made for DMX/DALI environment
Maximum energy and operational efficiency
eldoLED Lineardrivers are high-end PWM dimmers for flickerfree and smooth dimming, even in the very low ranges. The are available in 0–10 V, Dali and DMX, for single and multicolour.
Control and Programming
Control Mode DMX
DMX Channels 4
Protocols DMX
Electrical Specifications and Connections
Power Supply 12-28 VDC
Output Voltage 12-28 VDC
Maximum Output Current (A) 6 A
Power Connector in Open End
Power Connector out Open End
DMX Connector in Open end
DMX Connector out Open end
Mechanical Specifications
Length (mm) 155 mm
Height (mm) 23 mm
Width (mm) 50 mm
Weight 12 kg
IP Rating IP20 (indoor use only)
Housing Plastic
Colour Black
Thermal Specifications
Minimum Ambient Temperature -20 °C
Maximum Surface Temperature 50 °C
