Novastar NovaStar CVT10 Pro-S

10x gigabit ethernet to fibre converter - IP65

2x 10G optical output (main + backup)
10x 1G ethernet port
IP65 rated for temporary outdoor use
Single mode, transmission up to 10 km
19” / 2U design

The Novastar CVT10 Pro-S is an IP65-rated, cost-effective long distance transmission solution for medium to large LED screen applications. It converts up to 10 network signal cables into a single fibre cable. Its design enables you to install it easily, securely and reliably in a 19-inch rack or case with a 2 unit height.

The CVT10 Pro-S can be connected directly to al processors which are equipped with a fibre optic output.

This LED screen fibre convertor can be used both as receiver or transmitter and can therefore also be used with other Novastar processors. You'll need two devices (TX/RX) when using a processor without fibre optic output.

The CVT10 Pro-S can be used for sending data of 10 individual 1 Gb signals to a distance of up to 10 km. It comes with a power cord and a USB cable.

Outputs
Main Outputs    10

Optical
Fibre Mode      Single-mode
Maximum Transmission Distance  10000 m (32808.4 ft)
Wavelength      1310 nm

Electrical Specifications and Connections
Power Supply        100-240 V AC 50/60 Hz
Power Consumption   22 W
Power Connector In  powerCON TRUE1
Data Connector In   USB
Data Connector Out  etherCON, USB

Mechanical Specifications
Width (Including Handles)  483 mm (19.016″)
Width (Without Handles)    440 mm (17.323″)
Height (Without Handles)   88 mm (3.465″)
Depth (Including Handles)  280 mm (11.024″)
Depth (Without Handles)    250 mm (9.843″)
Weight                     5.9 kg (13.007 lb)
Rack Units                 2 U
IP Rating                  IP65
Colour                     Black

Thermal Specifications
Maximum Ambient Temperature  55 °C (131 °F)
Minimum Ambient Temperature -20 °C (-4 °F)
Operating Humidity           0-80 %rH

Included Items
Included Cables             powerCON TRUE1 cable, USB Cable
