Novastar ET4S-G (P2) Media Server

Max. output resolution: 4x 5120 x 2880 @60 Hz
Mosaic output support for all outputs
Each output supports up to 8192 pixels width or height
Kompas FX3 software license included (dongle)
NDI support

The NovaStar ET4S-G (P2) Media Server is designed for multimedia exhibition halls, stage performances and other creative fixed installation applications. It is equipped with the MPG2200 graphics card and supports up to 8K x 4K output. The ET4S-G (P2) supports up to four DP 1.4 mosaic outputs to easily drive creative mosaic displays on irregular screens. Splitting, merging and rotating are supported, and each output can be split into up to 64 partitions, enabling quick mapping settings and ultra-wide screen configurations. Up to 12 layers and 1 audio stream can be played back simultaneously.
The included Kompass FX3 software ensures seamless, ultra-clear and smooth video playback with support for common video formats including H.264, H.265, MPEG-4/2, WMV and VP9. Six USB 3.0 ports provide fast external storage and mouse/keyboard connectivity. The software offers user-friendly media library management and supports PowerPoint files, NDI sources, website sources, streaming media and text sources. Its intuitive and user-friendly interface makes it easy to control content playback. NovaStar’s Visual Intelligent Control Platform (VICP) allows remote playback control as well.
Please note that the ET2G-G (P2) does not support genlock input/output.

Inputs
Mono Inputs             1
Mono Input Connector    TS unbalanced 3.5 mm
Stereo Inputs           1
Stereo Input Connector  TRS balanced 3.5 mm

Outputs
DP1.4 (out)             4
HDMI (for Control)      1
USB 3.0                 6
Stereo Outputs          4
Stereo Outputs (type)   XLR 3P / TRS balanced 3.5mm

Control and Programming
Output Resolution       5120 x 2880
NDI Supported           Yes

Software Specifications
Supported Layers        12

Playback
Processor               12th Generation Intel Core

Server Specifications
AV Software Included    Yes
AV Software Package     Kompas FX3
Memory Type             DDR5
Memory Size             32 GB
Storage 1 Type          SSD
Storage 1 Size          250 GB
Storage 2 Type          SSD
Storage 2 Size          1000 GB
Graphics Card Type      MPG2200
Video RAM Type          GDDR5X
Video RAM Size          5 GB
Maximum Resolution Width  16384 px
Maximum Resolution Height 16384 px

Electrical Specifications and Connections
Power Supply            100-240 V AC 50/60 Hz
Power Consumption       500 W
Power Connector In      IEC
Data Connector          RJ45 In/Out, USB

Mechanical Specifications
Length (Including Handles)  483 mm (19.016″)
Length (Without Handles)    440 mm (17.323″)
Height (Including Handles)  184 mm (7.244″)
Height (Without Handles)    177 mm (6.969″)
Depth (Including Handles)   642 mm (25.276″)
Depth (Without Handles)     598 mm (23.543″)
Weight                      17 kg (37.479 lb)
Rack Units                  4 U
IP Rating                   IP20 (indoor use only)
Colour                      Black

Product Properties
Cooling                     Active

Extra Features
GenLock                     In & Out

Thermal Specifications
Maximum Ambient Temperature 40 °C (104 °F)
Operating Humidity          0-80 %rH

Included Items
Included Cables             DP-DP cable, HDMI-HDMI cable, IEC cable
Included Accessories        Keyboard (USB), Mouse (USB)
