Quality of Light performance in any DMX application
Optical isolation in the DMX interface improves the robustness against
incorrect wiring and mishandling. The isolation also improves the immunity of
the driver, and the connected DMX network, against surge events during, i.e.
lightning strikes
Control and Programming
Control Mode DMX
Electrical Specifications and Connections
Power Supply 120-250 VAC 50-60 Hz
Power Consumption 50 W
Power Connector in Terminal
Power Connector out Terminal
Mechanical Specifications
Length (mm) 153 mm
Height (mm) 305 mm
Width (mm) 76 mm
Weight 0.35 kg
IP Rating IP20 (indoor use only)
Housing Plastic
Colour Black
Thermal Specifications
Maximum Ambient Temperature 50 °C
Minimum Ambient Temperature -20 °C
