General Specifications
Nominal diameter12", 305mm
Power rating100Wrms
Nominal impedance8Ω
Sensitivity99dB
Chassis typePressed steel
Voice coil diameter1.75", 44.5mm
Voice coil materialRound copper
Magnet typeCeramic
Magnet weight50oz, 1.42kg
Frequency range80-5500Hz
Resonance frequency, Fs85Hz
DC resistance, Re7Ω
Mounting Information
Cut-out diameter11.1", 283mm
Diameter12.2", 309mm
Magnet structure diameter6.1", 156mm
Mounting slot dimensions0.31", 7.9mm Ø
Mounting slot PCD11.7", 297mm
Number of mounting slots4
Overall depth5.3", 135mm
Unit weight10.4lb, 4.7kg
Manufacturer:
Celestion
Ίντσες Μεγαφώνου / Κόρνας:
12"
Οι τιμές ΔΕΝ συμπεριλαμβάνουν ΦΠΑ 24%
