Artecta Havana Ribbon RGBW 24 V 4-in-1

5 m - 5050 LED - 2200 K

The Ribbon series are IP20 LED strips, suitable for dry indoor applications and the best series to be used in an aluminium profile (with a cover for protection against dust and moisture). As it is not coated, the Ribbon series has the best heat dissipation and longest life span. The Multicolour range exists of RGB, RGBW and RGBA strips. The different LED types offer multiple characteristics as luminous flux and light spread is defined by the number of LEDs per metre.

Source

Light Source Type LED

Light Source Quantity/m 60

Light Source Power 0.32 W

Light Source System SMD5050

LED Colour Type RGBW

Lumen Total 4250 lm

Lumen output/m 850 lm

Lumen Red 98 lm

Lumen Green 362 lm

Lumen Blue 90 lm

Lumen White 300 lm

CRI 82

CCT 2200 K

Optical

Beam Angle Circular 120°

Control and Programming

Dimmable Yes

Electrical Specifications and Connections

Power Supply 24 VDC

Power Consumption 96 W

Power/1 m 19.2 W

Driver Excluded

Mechanical Specifications

Length (m) 5 m

Maximum Length (m) 5 m

Cutting Length 100 mm

Height (mm) 2 mm

Width (mm) 12 mm

Weight 0.193 kg

IP Rating IP20 (indoor use only)

PCB Colour White

Thermal Specifications

Maximum Ambient Temperature 50 °C

Minimum Ambient Temperature -20 °C
