Hybrid HydraDrive provides smooth, flicker-free dimming down to 1 %
Ledcode2 supports several digital accessories and IoT applications
NTC interface for robust thermal management
Industry-best dimming performance for your fixture/application
Control and Programming
Control Mode DALI
Dali Ballast 1 Ballast
Protocols DALI 2
Dimmable Yes
Electrical Specifications and Connections
Power Supply 100-240 VAC 50-60 Hz
Output Voltage Vf/Vo Minimum 2 VDC
Output Voltage Vf/Vo Maximum 55 VDC
Power Consumption 30 W
Minimum Output Current (mA) 150 mA
Maximum Output Current (mA) 1400 mA
Power Connector in Open End
Power Connector out Open End
Data Connector in Open End
Data Connector out Open End
Mechanical Specifications
Length (mm) 130 mm
Height (mm) 28 mm
Width (mm) 72 mm
Weight 0.228 kg
IP Rating IP20 (indoor use only)
Material Metal
Housing Metal
Colour White
Thermal Specifications
Maximum Ambient Temperature 50 °C
Minimum Ambient Temperature -20 °C
Included Items
Included Accessories None
