Compact 65 W LED Spot Moving Head
7 bi-rotating gobos + open
8 colours + white
3-facet prism
Manually adjustable zoom
The Showtec Phantom 65 Spot is a compact and reliable 65 watt LED Spot Moving Head suitable for indoor venues. This Phantom 50 successor has manual focus, 3-facet prism and gobo- and colour wheels. The Showtec Phantom 65 Spot creates stunning optical effects with 7 precise bi-rotating gobos. Its compact one-clamp mount 6 kg design is ideal for quick rigging on stage. The Phantom 65 Spot is suitable for every event with either black and white housing. The mid-range priced Phantom 65 with razor sharp light beams and spectacular gobos, deliver a high performance/value ratio.
Source
Light Source Type LED
Light Source Quantity 1
Light Source Power 65
LED Colour Type CW
Lux @ 5m 1870
Lumen Total 2095
Optical
Beam Angle Circular (max) 16
Zoom Type Manual
Focus Manual
Control and Programming
Control Mode Auto, DMX, Manual, Master Slave, Sound
DMX Channels 8, 13
Protocols DMX
Display LCD
Dynamic Effects
Dimmer 0-100 %
Strobe 0-20 Hz
Prism 1 3-facet
Prism Index & Rotate No
Colour System Colour Wheel
Dichroic Colour Wheel 1 8
Gobo System Glass + Metal
Gobo Wheel Index & Rotate Yes
Gobo Wheel 1 7
Gobo Size 20
Movement
Pan 540
Tilt 270
Pan/Tilt Resolution 16-bit
Electrical Specifications and Connections
Power Supply 100-240 VAC 50-60 Hz
Power Consumption 180
Fuse 3
Power Connector in Power Pro Blue
Power Connector out Power Pro Grey
DMX Connector XLR 3P In/Out
DMX Connector in XLR 3P
DMX Connector out XLR 3P
Mechanical Specifications
Length (mm) 238
Width (mm) 202
Height (mm) 357
Weight (kg) 6
IP Rating IP20 (indoor use only)
Housing Metal, Plastic
Colour White
Product Properties
Cooling Axial fan
Rigging
Mounting Options Quick-Lock
Safety Attachment Yes
Thermal Specifications
Maximum Ambient Temperature 40
Certifications/Qualifications
Reference Standard CE
Included Items
Included Cables powerCON cable
Included Rigging Quick-Lock Bracket
