Electrical Specifications and Connections
Rated Current (A) 16 A
Flashover Voltage 110 V
Pins 4
Minimum Wire Size 1 mm²
Maximum Wire Size 2.5 mm²
Mechanical Specifications
Length (mm) 63 mm
Height (mm) 70 mm
Width (mm) 70 mm
Weight 0.101 kg
IP Rating IP44
Housing Plastic
Colour Yellow
Mounting Size 56 x 56 mm
Product Properties
Pin Connection Screw Terminal
Supplier Type Number CE 614-4
Contact Type Brass
Ground Lug Position 4H
Manufacturer:
Showtec
