Electrical Specifications and Connections
Rated Current (A) 16 A
Flashover Voltage 110 V
Pins 4
Minimum Wire Size 1 mm²
Maximum Wire Size 2.5 mm²
Cable Entry 6-15 mm
Mechanical Specifications
Length (mm) 138 mm
Height (mm) 82 mm
Width (mm) 55 mm
Weight 0.161 kg
IP Rating IP44
Housing Plastic
Colour Yellow
Product Properties
Pin Connection Screw Terminal
Supplier Type Number CE 214-4
Contact Type Brass
Ground Lug Position 4H
Manufacturer:
Showtec
