Novastar MX6000 Pro

8K LED Controller Main Frame for 141 Megapixels

Controls up to 141 million pixels
Supports 8x Input card and 8x Output card
Scaling function, 0-frame latency, frame rates up to 360 Hz
True 12-bit, HDR, wide colour gamut, 3D display technology
7 inch LCD touch panel

The Novastar MX6000 Pro is a professional 8K LED screen controller for large-screen rental services, xR/VP studios, TV productions, (e-)sports events, large fixed installations, etc. It supports true 12-bit colour depth, HDR, up to 360 Hz refresh rates, 0-frame latency, real-time multi-screen scaling and provides accurate brightness control, excellent colour and picture quality. There are several in- & output cards available which enable users to customise the processor to fit the needs of any project.
The MX6000 Pro can be controlled via its 7” touch screen in combination with the control knobs, via cascading Ethernet control and VMP software. It also supports the SNMP and Art-Net protocols. The control card is included, the input and output cards must be purchased separately. The MX6000 Pro is supplied with a dual power supply to ensure uninterrupted operation in the unlikely event that the main power supply fails.
Please note that only Armor and CX series receiver cards are supported. Older receiver cards like the MRV series are not supported.

Inputs
RS-232            1
Ethernet speed    1 Gbit/s
Input Slots       8

Outputs
S/PDIF (Out)      1
Output Slots      8

Software Specifications
Control Software  VMP

Extra Features
Scaling Function  Yes
Layers            32
GenLock           In & Out
DMX Control       Art-Net

Control and Programming
Display           Touch
Display Size      7 "
Maximum Loading Capacity  141 Mpx
Control Options           Ethernet, RS232

Electrical Specifications and Connections
Power Supply        200-240 V AC 50/60 Hz
Power Consumption   625 W
Power Connector In  IEC
Data Connector In   RJ45, USB
Data Connector Out  RJ45

Mechanical Specifications
Width (Including Handles)   483 mm (19.016″)
Width (Without Handles)     440 mm (17.323″)
Height (Including Handles)  266 mm (10.472″)
Depth (Including Handles)   539 mm (21.22″)
Weight                      31 kg (68.343 lb)
Rack Units                  6 U
IP Rating                   IP20 (indoor use only)
Housing                     Metal
Colour                      Black

Thermal Specifications
Maximum Ambient Temperature  45 °C (113 °F)
Minimum Ambient Temperature -10 °C (14 °F)
Operating Humidity           0-80 %rH

Included Items
Included Cables              CAT-5 Cable, IEC cable
