Converts DMX back into 0–10 V
Converts MIDI back into 0–10 V
Midi in and output
3 and 5-pin XLR
Last Hold Scene
Convert the signal from DMX512 to 72-Ch ANALOGUE output.
• Convert the signal from MIDI to 72-ChANALOGUE output
• The front panel alpha-numeric display
shows the DMX start address and
programming options
• The last scene remains when
DMX disappears
• Pre-store a scene and is available
for emergency
• Memory backup with EEPROM
• CHASE function can be selected
from 1 to 72 channel & speed control
• Select ANALOGUE output from +(-)10 V,
+(-)12 V and +(-)15 V
• Receive NOTE ON/OFF signal of MIDI
Electrical Specifications and Connections
Power Supply 240 VAC 50-60 Hz
Power Consumption 50 W
Power Connector in Schuko Plug
DMX Connector XLR 3P In/Out, XLR 5P In/Out
DMX Connector in XLR 3P, XLR 5P
DMX Connector out XLR 3P, XLR 5P
Midi Connector Yes
Mechanical Specifications
Length (mm) 483 mm
Width (mm) 126 mm
Height (mm) 44 mm
Installation Depth (excl. connector)126 mm
Weight 2.6 kg
Rack Units 1 U
IP Rating IP20 (indoor use only)
Housing Aluminum die-cast
Colour Grey
Product Properties
LED Indicators Operation mode, Signal
Thermal Specifications
Maximum Ambient Temperature 35 °C
Included Items
Included Cables Fixed Cable
Control and Programming
Control Mode DMX, MIDI, Stand Alone
DMX Channels 72
Display LED
