12 outputs of RGB or RGBW
Clear OLED display for easy setup
Including Phoenix terminals
Control by DMX or stand alone
The LED Dim 12 dimmer is a universal and versatile PWM dimmer which is suitable to use with constant voltage LED strips. It has 12 outputs which all can control 4-channel strips with a working voltage of 12 V to 24 V. Settings can be done easily by the OLED display. DMX connections can be done by RJ45 or 3-pin DMX plugs. The power supply as well the connections of the LEDs are user friendly by (easy removable) Phoenix terminal connections.
Control and Programming
Control Mode DMX
DMX Channels 48
Protocols DMX
Electrical Specifications and Connections
Power Supply 12-24 VDC
Output Voltage 12-24 VDC
Maximum Output Current (A) 15 A
Power Connector in Terminal
Power Connector out Terminal
DMX Connector in RJ45, XLR 3P
DMX Connector out RJ45, XLR 3P
Mechanical Specifications
Length (mm) 286 mm
Height (mm) 90 mm
Width (mm) 62 mm
IP Rating IP20 (indoor use only)
Housing Metal
Colour Black
Thermal Specifications
Maximum Ambient Temperature 40 °C
Certifications/Qualifications
Energy Efficiency Class T/B/D
