24” hinged multitouch screen + 2x HDMI for two external screens
15 motorised faders and RGB backlit controls
65 DMX universes, Art-Net, sACN, integrated LumenRadio
Freely configurable UI, advanced FX engine and powerful colour tools
Compact design ideal for theatres, venues and mid-sized productions
This product is available for pre-order. The official delivery date will be confirmed at a later stage. The images show a near-final production sample. Any differences in the final product will be purely cosmetic and minimal. All functionality, layout, controls and performance will be exactly as displayed.
The Infinity CHIMP G3 Core is a compact yet highly capable DMX lighting console designed for theatres, rental companies and mid sized productions. It features a hinged 24” multitouch screen and 15 motorised faders, 35 executor buttons, 4 rotary encoders, each with their freely-programmable multi-purpose key, and many more control buttons – all RGB backlit for clear feedback and visibility in dark FOH environments. Two external monitors can be added for even greater visibility. Its upgraded CPU/GPU ensures fast response times when handling large show files, complex effects or extensive fixture rigs.
The renewed G3 software engine introduces freely configurable screens, dynamic preset pools, a visual FX engine, refined colour tools (including colour calibration and CCT/Tint control) and a powerful filtering system that allows you to find and select fixtures with simple text input. With support for up to 65 DMX universes, free patchable DMX ports and integrated LumenRadio wireless DMX, the Core fits into both touring conditions and fixed installations. Connectivity includes USB-C, USB-A, 2x HDMI, 2x RJ45 network, audio I/O, MIDI I/O, 8x GPIO and 4x DMX outputs.
The redesigned control surface improves comfort during long programming sessions, with refined button shapes, lighter actuation force and an optimised chassis angle, making the Core reliable, intuitive and ready for daily professional use.
The CHIMP G3 Core is part of the third generation of the CHIMP platform, combining a completely renewed hardware architecture with a brand new software engine built from the ground up. Despite this major redevelopment, the G3 software remains instantly recognisable to existing CHIMP users. The familiar workflow, clear logic and operator friendly layout are all preserved, while a new foundation brings higher speed, smoother graphics and more creative tools than ever before.
Control and Programming
Control Mode Art-Net, DMX, LTC, MIDI, sACN
DMX Channels 33280
Patch mode Yes
Wireless LumenRadio
Display LCD, Touch
Display Resolution (Horizontal) 1920 px
Display Resolution (Vertical) 1080 px
Display Size 24 "
External Display Yes
External Display Resolution (Horizontal) 1920
External Display Resolution (Vertical) 1080
Unlimited Fixtures Yes
Cue Lists 10000
Encoder Wheels 4
Faders 15
Memories 99999
OSC (Open Sound Control) Yes
Playback Buttons 35
Playback Faders 15
Playback Pages 10000
sACN Yes
Art-Net Yes
SMPTE Timecode Yes
Effects Engine Yes
Universes 65
Electrical Specifications and Connections
Power Supply 100-240 V AC 50/60 Hz
Power Consumption 125 W
Power Connector In Power Pro True
DMX Connector In XLR 5P
DMX Connector Out XLR 5P
Data Connector In etherCON
Data Connector Out etherCON, HDMI, USB A, USB C
MIDI Connector Yes
HDMI Outputs 2
Ethernet Ports 2
Audio Triggers 3
Mechanical Specifications
Length (mm) 517 mm (20.354″)
Width (mm) 686 mm (27.008″)
Height (mm) 160 mm (6.299″)
Weight 25 kg (55.116 lb)
IP Rating IP20 (indoor use only)
Housing Aluminium, Metal, Plastic
Colour Black
Product Properties
Cooling Active
Desk Light 3P XLR female
Thermal Specifications
Maximum Ambient Temperature 40 °C (104 °F)
Minimum Ambient Temperature -5 °C (23 °F)
Included Items
Included Cables Power Pro True Cable
