Electrical Specifications and Connections
Flashover Voltage 300 V
Impedance 100 Ω
Connector 1 XLR 3P
Connector 2 XLR 3P
Cable Length 10 m
Pins 3
Conductor Resistance 80 Ω/km
Conductor Capacitance 65 pF/m
Capacity Inner conduct. Shield/Inner conduct. 78 pF/m
Outer Cable Diameter 6 mm
Outer Isolation Type PVC
Mechanical Specifications
Weight 0.48 kg
Material PVC
Colour Black
Product Properties
Contact Type Copper
1st Shield Oxygen Free Copper
Filler Material Cotton
Conductors 3
Thermal Specifications
Maximum Ambient Temperature 70 °C
Minimum Ambient Temperature -40 °C
