DAP EDCS-8210 8" Passive Ceiling Speaker 100 V - Black

Excellent price performance ratio

Modern and stylish design

Magnetic cover for easy installation and maintenance

The DAP EDCS series combine a good sound quality and stylish design in an affordable solution for commercial audio installations. These series is available in both white and black enclosures and are the right tool for any installation audio job.

Inputs

Peak Input Power 10 W

Transformer 100 V

Line Transformer Taps 5, 10 W

Passive Input Connection Open End

Audio Specifications

Speaker System Coaxial

Speaker Sensitivity (1 W/1 m) 93 dB

Speaker Impedance 8 Ω

Maximum SPL at 1 m 98 dB

Frequency Response Minimum 100 Hz

Frequency Response Maximum 15000 Hz

Woofer Diameter 8 "

Woofer Magnet Type Ferrite

Dispersion Angle Horizontal 360°

Dispersion Angle Vertical 180°

Mechanical Specifications

Height (mm) 88 mm

Width (mm) 232 mm

Length (mm) 232 mm

Weight 0.9 kg

IP Rating IP20 (indoor use only)

Housing ABS

Mounting Size Ø 210 mm

Colour Black

Rigging

Mounting Options Ceiling
