Outputs
Output per channel at 70/100 V at 20Hz > 20 kHz 12 W
Passive Output Connector Terminal
Sound Editing
Attenuation -/+ 3dB Per Step
Electrical Specifications and Connections
Backup Power Supply 24 VDC
Mechanical Specifications
Height (mm) 154 mm
Width (mm) 80 mm
Length (mm) 67 mm
Installation Depth (excl. connector) 50 mm
Diameter 50 mm
Material ABS
Colour White
Weight 0.18 kg
IP Rating IP20 (indoor use only)
Mounting Size 50 mm
Rigging
Mounting Options Flush, Surface, Wall
Product Properties
Thread M3
Included Items
Included Accessories Screws
