General Specifications
Nominal diameter12", 305mm
Power rating15Wrms
Nominal impedanceAvailable 8Ω or 15Ω
Sensitivity100dB
Chassis typePressed steel
Voice coil diameter1.75", 44.5mm
Voice coil materialRound copper
Magnet typeAlnico
Frequency range75-5000Hz
Resonance frequency, Fs75Hz
DC resistance, ReAvailable 6.4Ω or 11.8Ω
Mounting Information
Cut-out diameter11.1", 283mm
Diameter12.2", 309mm
Magnet structure diameter5.0", 128mm
Mounting slot dimensions0.31", 7.9mm Ø
Mounting slot PCD11.7", 297mm
Number of mounting slots4
Overall depth6.5", 165mm
Unit weight9.3lb, 4.2kg
Manufacturer:
Celestion
Ίντσες Μεγαφώνου / Κόρνας:
12"
