Eldoled POWERdrive AC 600 W Constant Current

HydraDrive provides smooth, flicker-free dimming down to 1 %

Tunable dynamic response

Ledcode supports most constant current LED modules and arrays

NTC interface for robust thermal management

Industry-best dimming performance for your fixture/application

The POWERdrive 6060R1 is a rackmount LED power supply for indoor LED lighting applications. It is capable of delivering up to 600 W through up to 32 outputs and various LED configurations. Its 32 outputs can be controlled individually by DMX/RDM, while its DALI interface supports up to 4 blocks of outputs. It is also possible to control all outputs at once through a 0-10-V input. For extensive thermal management, one NTC thermistor can be connected for every 4 outputs (up to 8 NTCs in total). The POWERdrive 6060R1 is also LEDcode compatible.

For connection of the LED, DALI, NTC, and LEDcode wires, 2- and 4-pole Phoenix Contact FMC 1.5/2-ST-3.5-1952267 and 1.5/4-ST-3.5-1952283 are used. Please note that these are not included and should be purchased separatey.

Control and Programming

Control Mode DALI , DMX

Electrical Specifications and Connections

Power Supply 120-250 VAC 50-60 Hz

Power Consumption 600 W

Power Connector in IEC

DMX Connector in RJ45

DMX Connector out RJ45

Data Connector in Phoenix

Data Connector out Phoenix

Mechanical Specifications

Length (mm) 482.6 mm

Height (mm) 44.5 mm

Width (mm) 325 mm

Weight 6.3 kg

IP Rating IP20 (indoor use only)

Material Metal

Housing Metal

Colour Black

Thermal Specifications

Maximum Ambient Temperature 50 °C

Minimum Ambient Temperature -20 °C

Included Items

Included Accessories None
